Upgrade your high beam headlights with ORACLE's S3 Pro LED Conversion Bulbs - delivering 4,860 lumens of crystal clear 6000K light in a sealed waterproof heatsink design that eliminates external drivers and cooling fans. True plug & play H11 fitment. Universal application.

Part Number: S5235-001

✓ 4,860 Lumens
✓ 6000K Crystal White
✓ Plug & Play H11
✓ High Beam
✓ Waterproof Heatsink
✓ CSP LED Chip
✓ No External Drivers
✓ 3-Year Warranty

Bulb Fitment: H11 | Application: High Beam Headlight

Product Overview ▼

ORACLE Lighting S3 Pro LED Conversion Bulbs instantly upgrade your high beam headlights with 4,860 lumens of crystal clear 6000K output. The electronic components are housed in a sealed waterproof heatsink design, eliminating the need for external drivers and cooling fans.

The CSP (Chip Scale Package) LED Chip delivers a small form factor with high-intensity output and lower heat value - resulting in an industry-leading 130 lm/W luminous efficacy ratio. The low-profile design reduces common bulb fitment clearance issues for an easy plug & play DIY installation.

ORACLE S3 Pro LED Integrated Heatsink Design

Why Choose the ORACLE S3 Pro LED Bulbs? ▼

4,860 Lumens of Output - dramatically brighter than stock halogen high beams; maximum distance visibility when you need it most
6000K Crystal White - clean, modern HID-like color temperature that improves road contrast and visibility
Sealed Waterproof Heatsink - integrated design eliminates external drivers and cooling fans
True Plug & Play - direct H11 fitment, no wiring, no cutting, installs in minutes
CSP LED Technology - industry-leading 130 lm/W efficacy; maximum output with lower heat value
Low-Profile Design - reduces common bulb fitment clearance issues
3-Year Limited Warranty - backed by ORACLE Lighting's quality guarantee

Performance & Technical Specifications ▼

Part NumberS5235-001

Bulb FitmentH11

ApplicationHigh Beam Headlight (Universal)

Brightness4,860 Lumens per bulb

Color Temperature6000K (Crystal White)

Power Draw18W per bulb

Current Demand1.5 Amp

Operating Voltage12V / 24V

Luminous Efficacy130 lm/W*

LED Chip TypeCSP (Chip Scale Package)

Housing Material6160 Aluminum Alloy

PCBDouble Layer Copper

Waterproof RatingSealed / Waterproof Heatsink

Warranty3-Year Limited

*Industry-Leading Efficacy Ratio

⚠️ CAN-BUS Note: Dodge, Chrysler, Jeep, or later-model EU vehicles (Mercedes, BMW, Audi, etc.) may require additional CAN-BUS decoder harnesses if flashing, strobing, or shutoff occurs with engine on.

Key Features & Benefits ▼

CSP Chip Scale Package LED - small form factor, high-intensity output with lower heat value
Integrated Sealed Waterproof Heatsink - no external drivers or fans needed
Low-Profile Design - reduces common bulb fitment clearance issues
Industry-Leading 130 lm/W luminous efficacy ratio
12V/24V Dual-Voltage compatibility
Direct Plug & Play H11 replacement - no modifications required
3-Year Limited Warranty backed by ORACLE Lighting

Fitment ▼

This kit fits any vehicle using an H11 high beam headlight bulb. Verify your vehicle's headlight bulb size before ordering. Common H11 high beam applications span Toyota, Honda, Chevrolet, Ford, Nissan, Subaru, and many others.

💡 Not sure if H11 is the correct size for your high beams? Check your owner's manual or a bulb fitment guide before ordering.

What's Included ▼

(2) H11 S3 Pro LED High Beam Headlight Bulbs
Installation Guide
ORACLE Lighting Warranty Card

Installation Guide & Resources ▼

Estimated Install Time: Under 30 minutes
Tools Needed: None - true plug & play
Skill Level: Beginner DIY friendly

Download Installation Guide

Warranty, Shipping & Returns ▼

ORACLE Lighting S3 Pro LED Bulbs are covered by a 3-Year Limited Warranty against defects in materials and workmanship.
